Image Acquisition Solutions: ProcFG vs InfiniVision

Compare ProcFG and InfiniVision to choose the right FPGA image acquisition architecture for your vision system. ProcFG supports deterministic, per-camera acquisition, while InfiniVision enables scalable, synchronized multi-camera acquisition on Gidel FPGA-based frame grabber platforms.

View Products Contact Sales

Image Acquisition Architecture: Overview & Comparison

Key Features
Product Name	ProcFG	InfiniVision
System Architecture
Availability	Available on all Gidel frame grabber systems	Available on all Gidel frame grabber systems
Camera Interfaces	GigE Vision CoaXPress Camera Link	GigE Vision CoaXPress Camera Link
Acquisition Scale	Up to ~120 FPS per stream	100+ synchronized cameras >100,000 FPS aggregate throughput
Synchronization Model	Independent, per-camera deterministic acquisition	Global, hardware-level synchronization across all cameras
Grabbing & Recording Modes	Uncompressed image streams	Uncompressed image streams Compressed image streams
Frame Size Handling	Static frame sizes	Dynamic frame sizes and varying incoming formats
ROI Handling	Selected ROI grabbing	Dynamic ROI handling per camera and per frame
Inline FPGA Processing	Optional inline full customized Image Signal Processing (ISP) via ProcVision	Optional inline full customized Image Signal Processing (ISP) via ProcVision Optional inline image compression
Optimization Focus	Line-scan and continuous acquisition applications	Large-scale, high-density multi-camera systems
Software & Extensibility	Dedicated API per camera Built-in image debugging tools Integrated with Gidel Grabber SDK	Integrated with Gidel Grabber SDK High-bandwidth PCIe-based host interface

Choosing the Right FPGA Image Acquisition Architecture

ProcFG and InfiniVision run within Gidel’s FPGA-based image acquisition ecosystem, but they address different system requirements. ProcFG is designed for deterministic, per-camera acquisition where frame integrity, predictable behavior, and long-duration stability are critical.

InfiniVision is designed for large-scale synchronized acquisition across many cameras, supporting high aggregate throughput, flexible frame handling, and centralized multi-camera control.

Together, ProcFG and InfiniVision allow system designers to choose the acquisition architecture that best matches the application, from controlled single-camera or line-scan pipelines to scalable multi-camera vision systems.
