HawkEye-20GigE:

Dual 10 GigE Vision Frame Grabber

2 x 10 GigE Vision Frame Grabber & Image Processing System

Grabbing from up to 2 x 10 GigE, 4 x 5 GigE, etc. cameras
Zero frame loss and almost zero CPU utilization
Ideal for Recording & Streaming solutions
Inline FPGA image processing options include:
- Real-time detection for object, event, or feature identification
- On-FPGA real-time compression: JPEG, Lossless, Quality+
- Real-time High Dynamic Range (HDR) correction
Memory: up to 17 GB
Form factor: full-height, single-slot, half-length PCI Express card
Optional: Low Profile

Dual 10 GigE Frame Grabber

The HawkEye-20GigE is a high-performance GigE frame grabber designed for real-time image acquisition, processing, and compression in demanding multi-camera vision applications. Powered by Altera Arria 10 FPGA technology, it supports up to 2 × 10 GigE Vision cameras directly and can scale to multiple synchronized cameras via a network switch. With dual SFP+ ports delivering 20 Gb/s bandwidth and a low-profile PCIe form factor, it guarantees zero frame loss, ultra-low latency, and negligible CPU load, making it ideal for mission-critical environments.

Dual 10 GigE Vision Acquisition with Real-Time FPGA Image Processing

The HawkEye-20GigE is available as a plug-and-play 10 GigE Vision frame grabber or as part of a complete Imaging & Vision system with real-time FPGA preprocessing, image enhancement, and compression options.

The built-in FPGA can process image data during acquisition, before it reaches the host PC. This helps reduce bandwidth, storage, and host processing load while preserving low-latency performance for high-speed camera streams.

Optional FPGA processing includes Compression, HDR correction, Detection, and additional image enhancement modules.

Real-Time FPGA Processing Helps Enable:

Reduced bandwidth for high-throughput image acquisition
Low-latency processing directly in the acquisition flow
Extended recording time through real-time compression
Lower host processing load by offloading selected tasks to the FPGA
Custom image pipelines using Gidel IPs or user FPGA logic

For the full list of available image processing and enhancement options, please refer to the Options tab.

Flexible Operating Modes

The HawkEye-20GigE supports two operating modes, selectable via firmware, allowing system designers to adapt the frame grabber to different GigE Vision workflows and acquisition requirements.

InfiniVision: Ideal for synchronized multi-camera setups, combining all data—even across multiple cards—into a single buffer with dynamic resolutions and formats.
ProcFG: Tailored for precision applications, offering fixed frame sizes, pixel formats, and ROI grabbing (uncompressed).

As a result, the HawkEye-20GigE frame grabber adapts to a wide range of GigE Vision workflows, from complex multi-camera AOI systems to single-camera applications that demand reliable, high-performance, and deterministic image acquisition.

InfiniVision: Multi Camera Acquisition and Synchronization

Gidel’s InfiniVision architecture addresses critical multi-camera challenges, including bandwidth, synchronization, connectivity, and scalability. Consequently, the HawkEye-20GigE supports dual 10 GigE Vision interfaces and can manage larger synchronized camera networks via switches.

A PCIe Gen3 x8 interface ensures CPU-free, ultra-fast data transfer, while FPGA-based on-board buffers enhance acquisition stability and enable real-time image processing. As a result, the HawkEye-20GigE delivers reliable, deterministic performance in high-speed, high-resolution vision systems.

SDK and Development Tools

The HawkEye-20GigE is supported by Gidel’s SDK, offering intuitive GUIs and APIs for streamlined system integration. Additionally, the ProcVision Suite provides advanced FPGA programming, debugging, and validation tools. Consequently, developers can rapidly customize data flows, implement real-time processing, and optimize compression pipelines, reducing development time and risk.

Why Choose the HawkEye-20GigE Frame Grabber?

Dual 10 GigE Vision FPGA frame grabber for high-speed multi-camera image acquisition
Up to 20 Gb/s aggregate input bandwidth
FPGA architecture for low-latency acquisition, processing, recording, and streaming
Scalable InfiniVision architecture for synchronized multi-camera systems
Advanced SDK and ProcVision Suite for rapid development and integration
Optional real-time FPGA processing, image enhancement, and compression IPs

The HawkEye-20GigE is the ideal choice when your workload requires high-speed GigE Vision acquisition, low-latency FPGA processing, and reliable image transfer to a host PC.

General

Protocol

GigE Vision 2.1

Supported Interfaces

10 GigE Vision
5 GigE Vision
2.5 GigE Vision
1 GigE Vision

Camera Input Options

2 x 10 GigE cameras
4 x 5 GigE cameras
8 x 2.5 GigE cameras
20 x 1 GigE cameras

Camera Input Connectors

2 x SFP+, fiber optic
2 x RJ45, copper

Additional Connectors

JTAG
VGA15-pin for connecting GPIO's to the bracket

Advanced Features

On-the -fly selective ROI acquisition
Chunk Data

Image Formats

Mono, Bayer, RGBA (8, 10, 12, 14 and 16 bits/color)
RGB (8, 10 and 12 bits/color)

Max. Resolution

Horizontal: 16 K pixels (64-bit)
Vertical: 65 K lines

Maximum Acquisition Throughput

20 Gb/s

Real-Time FPGA Image Compression

Supports optional FPGA-based compression options.
For the full list, please refer to the Options tab.

Real-Time FPGA Image Processing & Enhancements

Supports optional FPGA image processing and enhancement modules.
For the full list, please refer to the Options tab.

Host Bus

PCIe x8 Gen. 3

On Board Memory

Up to 17 GB

Camera Types

Area
Line Scan

Form Factor

Full-height, single-slot, half-length PCIe card

GPIO

GPIO #1:

4 x RS422 INPUTS
Optional input clk
1 x Optocoupler input

GPIO #2:

1 x RS422 INPUTS
2 x Opto-coupler inputs
2 x 3-30V @ 0.8A outputs
LVTTL IO
12V/1A power supply

GPIO #3: (for board-to-board connection):

12 x LVTTL IO (5V TTL tolerant)

Power

5-32W: Depends on user application and FPGA Type

Cooling

Passive cooling
Active cooling (Fan)

MTBF

Passive colling: 1.7M hours
Active colling: 350K

Environmental conditions

Temperature

Operating ambient air temperature: 0 – 55° C

Humidity

Continuous Operation: 10 - 80% (non-condensing)
Peak Operation: 10 - 90% (non-condensing)

Environmental Compliance

Real-Time FPGA Image Compression

Real-Time FPGA Image Processing & Enhancements

HDR Correction – High Dynamic Range correction from a single exposure
Detection – Enables real-time object, event, or feature detection at the acquisition stage
Chromatic Aberration Correction – Reduces color fringing caused by optical misalignment
Dynamic Luminance Balance – Preserves consistent brightness under changing illumination
White Balance – Maintains color accuracy across variable lighting conditions
NUC – Non-uniformity correction for improving sensor response consistency
BPR – Bad pixel replacement for correcting defective or unstable pixels
Morphological operations – Open/Close operations using a round structuring element

User FPGA code

Users can integrate their own FPGA code alongside Gidel IPs.

For more information, refer to the FPGA Processing tab

Form Factor

Low profile (Comes without the IO connector)

The HawkEye-20GigE Frame Grabber is a highly modular solution, designed to be tailored to meet unique application requirements.

Looking to adapt the HawkEye-20GigE to match your vision?

Contact Our Experts

The HawkEye-20GigE frame grabber offers two powerful customization paths to meet specific application requirements:

Pre-Configured FPGA Features
Gidel develops a range of pre-embedded modules tailored to your specifications, including real-time compression, image processing, and enhancement options.
For the full list of image processing and enhancements, please refer to the Options tab.
User-Level FPGA Customization
Leverage Gidel’s development tools and IP libraries to integrate your proprietary FPGA logic and extend the system’s capabilities for acquisition, image processing, and control.

The Gidel ProcVision Suite delivers a complete toolchain for advanced user-level FPGA customization of the data flow, image pipeline, image processing, and more, ensuring optimal performance for your vision or imaging application.

Gidel can also integrate customer algorithms into the FPGA or develop custom FPGA logic according to specific application requirements.

HawkEye-20GigE: FPGA resources comparison

Model	HawkEye-20GigE-48	HawkEye-20GigE-16
FPGA	Arria10-480-3	Arria10-160-2
FPGA-ALM	182K	61K
FPGA-M20K	1,438	440
FPGA-18*19 Multipliers	2,736	312
Peripheral Memory:
DRAM A capacity	1 GB	1 GB
DRAM A sustain bandwidth	5.6 GB/s	6.4 GB/s
SoDIMM B capacity	0,4,8,16 GB	-
SoDIMM B sustain bandwidth	9.6 GB/s	-

Grabbers SDK

InfiniVision

Designed for acquisition from a large number of cameras (100+), with an option for embedded real-time compression.

ProcFG

Optimized for line-scan camera acquisition, combining ROI-based grabbing with integrated debugging and analysis tools.

Application Interfaces

GUI Applications

InfiniVision
ProcFG
CameraConfig – Camera discovery and configuration
ggvcon – GigE Vision network configuration

APIs

InfiniVision with supporting examples
ProcFG with supporting examples
Gen<i>Cam GenTL producer libraries compatible with C/C++ compilers
InitCam for developing user Gen<i>Cam camera configuration application
GigE for developing camera network communication applications

Software Compatibility

Third-party software

MVTec Halcon machine vision software
Camera control Gen<i>Cam based application

Operation Systems supported

Windows 11
Windows 10
Windows Server 2022
Windows Server 2019
Windows Server 2016
Linux (kernel 2.6.x- 6.12)

Please note: Linux version doesn’t include the ProcFG/InfiniVision GUI, just the API.
